Adhesion control between wheel and rail is a critical factor in the performance, safety and energy efficiency of electric rail traction systems. This paper proposes an adaptive fuzzy based approach for optimal adhesion control in electric heavy duty rail traction. A feedforward fuzzy logic network is trained using simulated adhesion data derived from a dynamic traction model incorporating wheel- rail creep forces and environmental parameters. The proposed controller is integrated into a vector controlled traction drive model in MATLAB/Simulink. Simulation results demonstrates improved adhesion utilization. A six-axle locomotive dynamical model and empirical adhesion characteristic are used to evaluate the methods in single- and multi-axle scenarios. Simulation results demonstrate that the proposed hybrid method substantially improves adhesion utilization, while maintaining robustness across dry, wet, and low-adhesion surfaces. The focus of this paper is on analyzing the adhesion coefficient.

This paper proposed a fuzzy network-based approach for optimal adhesion control in electric heavy duty rail traction systems. Unlike threshold-based controllers that rely on empirical torque reduction ratios, the proposed algorithm responds proactively by estimating the adhesion limit and compensating for dynamic disturbances. The proposed hybrid adhesion control method demonstrates enhanced dynamic response, improved robustness, and higher adhesion utilization efficiency across diverse rail conditions. These results validate the feasibility of integrating intelligent surface identification with adaptive torque regulation for heavy-duty locomotives.

[1]Y. Li et al., “Adhesion Control of Heavy Haul Locomotives: A Review,” IEEE Transactions on Vehicular Technology, vol. 68, no. 8, pp. 7554–7568, 2019. [2]Wang, S., Wang, X., Huang, J., Sun, P., & Wang, Q. (2021, August). Adhesion Control of High Speed Train Based on Vehicle-control System. In 2021 IEEE 16th Conference on Industrial Electronics and Applications (ICIEA) (pp. 142-147). IEEE. [3]X. Wang and Z. Zhang, “Research on Re-adhesion Control Strategy of Heavy-Haul Locomotives under Complex Conditions,” Journal of the China Railway Society, vol. 42, no. 4, pp. 52–59, 2020. [4]He J, Liu G, Liu J, Zhang C and Cheng X,Identification of a Nonlinear Wheel/Rail Adhesion Model for Heavy-Duty Locomotives [J] , IEEE Access, 2018,6:50424-50432 [5]Zhao Hongwei. HXD1 Electric Locomotive [J]. Electric Drive for Locomotives, 2009, (1): 1-5. [6]Wang Xiao. Research on Locomotive Adhesion Control Technology [D]. Chengdu: Southwest Jiaotong University, 2012 [7]Djukić, M., Rusov, S., & Mitrović, Z. (2010). A fuzzy model for an increase in locomotive traction force. Transport, 25(1), 36-45 [8]Huang Jingchun and Ren Qiang and Wang Song and Fan Xiaoli, “Electric locomotive adhesion control based on improved disturbance observer,” computer simulation, vol. 30, no. 10, pp. 208–212, 2013 [9]Liu W.Y, Han J.G and Lu X.N ,A high speed railway control system based on the fuzzy control method[J] Journal Expert Systems With Applications ,2013.40(15): 6115–6124 [10]R. Palm and K. St0rjohann, “Torque Optimization for a Locomotive using Fuzzy Logic,” in Proceedings of the 1994 ACM symposium on Applied Computing, 1994, pp. 105–109. [11]S.-K. Kwon, U.-Y. Huh, H.-I. Kim, and J.-H. Kim, “Re-adhesion control with estimated adhesion force coefficient for wheeled robot using fuzzy logic,” in 30th Annual Conference of IEEE Industrial Electronics Society, 2004. IECON 2004, 2004, pp. 2530-2535 Vol. 3. [12]Hua C, ban T, ishida M, nakahara T, Influential Factors on Adhesion between Wheel and Rail under Wet Conditions[J] .Jurnal of railway technical institue. 2012.53(04):223-230. [13]Ishizaka K ,Lewis S.R.and Lewis R,The low adhesion problem due to leaf contamination in the wheel/rail contact:Bonding and low adhesion mechanisms[J] ,International journal of the seince and technologie of friction Wear, 2017, 378-379:183-197, [14]Smejkal D, Omasta M and Hartl M,An Experimental Investigation of the Adhesion Behavior between Wheel and Rail under Oil, Water and Sanding Conditions[M],Modern Methods of Construction Design. Springer International Publishing, 2014. [15]Wang, S., Zhang, W., Huang, J., Wang, Q., & Sun, P. (2019). Adhesion control of heavy-duty locomotive based on axle traction control system. IEEE Access, 7, 164614-164622. [16]Radionov I. A. and Mushenko A.S,The method of estimation of adhesion at”wheel-railway”contact point [C] ,International Siberian Conference on Control and Communications (SIBCON), 2015:1-5. [17]Sun Jianfang. Research on Adhesion Control Technologyfor Heavy Haul Locomotives [D]. Chengdu: Southwest Jiaotong University, 2013. Wang, S., Shen, Z., & Huang, J. (2022, May). Adhesion Control of Bogie-Controlled Inner-city Trains. In 2022 IEEE 5th International Electrical and Energy Conference (CIEEC) (pp. 4143-4148).
